Specification
| Motor |
ADM 4010 |
| Propeller |
17 inch |
| ESC |
40 A |
| KV Rating |
330 KV |
| Battery |
6S |
| Thrust per Rotor |
0.6 – 1.0 kg |
| Takeoff Weight of Quadrotor |
2.4 - 4.0 kg |
Price Details
CAD Drawing
| Propeller |
Voltage (V) |
Throttle (pwm) |
Current (A) |
Power (W) |
Thrust (g) |
Speed (rpm) |
Efficiency (g/W) |
Temp (°C) |
| 17 x 5.8 |
25.11 |
1300 |
1.0 |
25.1 |
346 |
2105 |
13.7 |
35 |
| 25.09 |
1350 |
1.2 |
30.1 |
384 |
2311 |
12.75 |
| 25.07 |
1400 |
1.7 |
43.8 |
557 |
2594 |
12.71 |
| 25.04 |
1450 |
2.0 |
50.1 |
619 |
2767 |
12.18 |
| 25.00 |
1500 |
2.4 |
60.0 |
700 |
2928 |
11.66 |
| 24.93 |
1550 |
2.5 |
62.3 |
893 |
3168 |
14.32 |
| 24.89 |
1600 |
3.6 |
89.6 |
1086 |
3479 |
12.12 |
| 24.87 |
1650 |
4.8 |
119.2 |
1269 |
3619 |
10.64 |
| 24.72 |
1700 |
6.0 |
148.3 |
1360 |
4006 |
9.17 |
| 24.68 |
1750 |
6.5 |
160.4 |
1535 |
4266 |
9.59 |
| 24.58 |
1800 |
7.8 |
191.7 |
1719 |
4501 |
8.96 |
| 24.51 |
1850 |
9.6 |
235.2 |
1809 |
4537 |
7.69 |
| 24.33 |
1900 |
11.5 |
279.7 |
1970 |
4620 |
7.06 |
